SINGLE COIL SLURRY SEALS

CS42 Standard Cartridge Single Seals Designed For Use In Rotating Shaft Equipment,Close-Coupled Pumps, Vertical Pumps and ANSI/DIN Pumps

SINGLE COIL SLURRY SEALS developed for light fouling, dirty media and clogging type application. Single Spring designed and is depended on the Shaft Rotation and also allows it to fit on to a normal shaft without any balancing step. The slurry mechanical seals drive of this seal is realized by grub screw which lock onto the shaft. The seal has a limited axial length, compact shape which allows easy mounting. It is single acting inside mounted unbalance pusher mechanical seals.

Single Spring Cartridge Seals

(Type CS42)

Single Coil Slurry seals is a compact balanced seal specially developed for handling sludges, slurries, polymerising fluids and thick syrups containing 30-40%.

Single spring slurry seals have single coil spring construction & has a Non Clogging Spring Construction feature giving better seal life.

This compact design Multi Coil slurry seal permits to use in all types of centrifugal pumps.

  • Single seal
  • Compact Cartridge design
  • Balanced Seal
  • Independent of direction of rotation
  • Multiple Spring non contact arrangement
  • Outside mounted
Seal Ring Face   : Carbon, Silicon, TC
Mating Ring Face   : Silicon, TC
Secondary Seals   : Viton/PTFE/GFT
Metal Parts   : SS 316, Alloy 20,
Pressure   : up to 30 Bars
Temperature   : (-)50 to 180°C
Speed   : up to 15 m/s
Size   : 10 to 150mm

Specially used in paper industries, petrochemicals, petroleum refinery etc

Item No Description
1 Seal Ring
2 Mating Ring
5 Bellow Unit
6 Gaskit
7.1 Graphoil
12 Grubscrew
13 Allen Bolt
19 Drive Collar
