CAPSULATED SPRING MECHANICAL SEALS
035B Multiple Spring Capsulated Seals Widely Used For Dirty, Abrasive And Solids Containing Media In Raw Sludge Pumps and Sugar Industry Pumps
We are based in Mumbai, India is specialized capsulated multi spring seals Manufacturer Company in the market. We export and supply all kinds multi spring seals products. We offer the products like O Rings mechanical seals and others as per the different industrial requirements. Our products include Multi Spring Unbalanced Seal, Multi Spring Balanced Seal, Reversed Balanced Seal, and Dry Running Mixer Seals. We have a group of devoted and various industrial experts who give their best to meet the target of the company. These Capsulated Spring Seals are tough, resistance to abrasion and are thermally stable. Our valued customers can avail from us Capsulated Spring Seals in different specifications and sizes, as per their requirements.
Capsulated Spring Balanced Mechanical Seals
Capsulated Spring Seals are a cost effective version of a Balanced seal They feature the same rugged and reliable construction as the Multi spring unbalanced seals.
capsulated Balanced seals designed for media containing solid slurry particles. The springs are protected from solidifying media resulting in high reliability of the seal. This seals are independent of direction of rotation.
- Multiple Spring Mechanical Seal
- For plain shaft
- Single acting
- Balanced
- Inside mounted
- Independent of direction of rotation
- Non-Contact Spring
| Seal Ring Face | : Carbon, Silicon, TC |
| Mating Ring Face | : Carbon, TC |
| Secondary Seals | : Elastomer/PTFE/GFT |
| Metal Parts | : SS 316,Alloy 20,Hastelloy C |
| Pressure | : 6 bars (Max) |
| Temperature | : (-)20c to (+)100c |
| Speed | : 2900 rpm (Max) |
| Size | : 18 mm to 100 mm |
General Chemicals Media Containing solids particles Acids & Alkalies
| Item No | Description |
|---|---|
| 1 | Seal Ring |
| 2 | Mating Ring |
| 4.1 | O-Ring |
| 4.2 | O-Ring |
| 4.3 | O-Ring |
| 10 | Spring |
| 12 | Grub Screw |
| 15 | Retainer |
| 17 | Drive Coller |
