General Purpose Water Service Rotary Joints
Water / General Purpose Rotary Joints Suitable For Cooling Water, Hot Water, Steam ,Hot Oil and Poor Water Quality Applications
The Type-MSJ12 has mono and dual port for transfer of media. Pair of Ball Bearings for alignment of rotor with housing. Single or Multi Spring for Seal faces and Elastomers. A key maintenance feature is the
cartridge design. This is easily replaceable & serviceable (on site) used for water and environment
of severe condition i.e poor water quality.This equipment is manufactured by using premium raw materials.
Water, Hot Water and General Purpose Rotary Joints
MSJ21 Rotary Joints
- Monoflow and dualflow design
- Self-supported rotating union
- Radial housing connection
- Balanced mechanical seals
- Easy and quick replacement of sealing components
- Keyed rotor seal
- Ball bearings lubricated for life
- E.L.S. (Extended Life Service) seal combination for poor water quality
- Brass, Carbon Steel, Stainless Steel, C.I housing and stainless steel rotor
- Special options include threaded vent holes
| Seal Ring Faces | Carbon Graphite/Silicon Carbide for water; Tungsten Carbide/Silicon Carbide for severe conditions such as poor water quality |
| Elastomer | Viton, EPDM, NBR, |
| MOC | SS 316, Carbon Steel, C.I |
| Size | 2″ (DN50) – 4″ (DN100) |
| Media | : Water, Steam, Hot Oil |
| Max. Pressure | : 51.7 bar |
| Max. Temperature | : 121°C |
| Max. Speed | : 3500 rpm |
Do Not Work With Maximum Pressure At Maximum Speed.
- Semiconductor
- Oil And Gas
- Paper And Corrugating
- Printing And Packaging
- Plastics
- Agriculture And Construction
- Food And Medical
- Tire And Rubber
- Chemical
“Deublin” 55/57 series
“Kadant” RX series
“Rototech” 3000 deries
“Rotofluid” 400 series
“Rotoflux” S series
“Maier” DP series
“Haag-zeissler” 9001ND series
“Filton” RE/REB/PB series
Duffnorton” 600 series
“Fourwent” FDU 5100/5200 series
“Txuan” BE/H Series
“Pearl Joint” RXE/RXH Series
