SPLIT MECHANICAL SEALS
SS65 Single Cartridge Split Seals For Use In Mixer Equipment, Displacement Pumps, Stock Pumps And Cooling Water Pumps
We are offer some of our products are PTFE Seals, Metal Bellow Seals, Welded Metal Bellow Seals, Mechanical Metal Bellow Seals, Spring Seals, rubber bellow Seals and Seal replacement parts.
The welded metal bellow seals products make use of the durability, pressure resistance and uniform displacement include bellows seals and vacuum bellows in semiconductor or electronic parts manufacturing facilities, and have earned a reputation for high performance.
Split Seals
Split Mechanical Seals are designed for the equipment where dismantling & assembly of the machine is difficult job.
Split seals is a unique design with minimum components for assembling the seal and allow user to install the seal in minimum time.The multi spring design keep the faces uniformely in contact.
The split seal face is balanced covered with split O-Ring as a sealing member. Slots provided in the housing facilitates fitting the seal on various equipments with different PCDs. in Split Mechanical seals Product leakage across the faces is minimized by maintaining rotor and stator face squareness with a robust, extended rotor assembly.
- Single seal
- Cartridge Unit
- Balanced Seal
- Independent of direction of rotation
- Multiple Spring arrangement
- Stationary Spring
| Seal Ring Face | : Carbon, Silicon, TC |
| Mating Ring Face | : Silicon, TC |
| Secondary Seals | : Viton/PTFE/GFT |
| Metal Parts | : SS 316, Alloy 20, 904L |
| Pressure | : 10 bars (Max) |
| Temperature | : (-)50c to (+)280c |
| Speed | : 2900 rpm (Max) |
| Size | : 16 mm to 150 mm |
Ideal for paper mills, waste water treatment facilities, soda ash processing and light chemical plants.
| Item No | Description |
|---|---|
| 1 | Seal Ring |
| 2 | Mating Ring |
| 5 | Bellow Unit |
| 6 | Gaskit |
| 7.1 | Graphoil |
| 12 | Grubscrew |
| 13 | Allen Bolt |
| 19 | Drive Collar |
