CARBON VS SILICON VS TUNGSTEN CARBIDE

When a mechanical seal fails before its expected service life, the root cause is very often traced back to one decision made early in the selection process: the seal face material. Carbon, Silicon Carbide (SiC), and Tungsten Carbide (TC) are the three most widely used seal face materials across pumps, mixers, agitators, and compressors — but each behaves very differently depending on the fluid, pressure, temperature, and operating conditions involved.

At Micro Seals, we’ve worked with maintenance engineers and plant operators across process industries, water treatment plants, chemical units, and oil & gas facilities, helping them troubleshoot premature seal failures that often trace back to an incorrect material pairing. This guide breaks down the real-world strengths, weaknesses, and ideal applications of each material so you can make a confident, informed decision.

• Material Selection
• Carbon Graphite
• Silicon Carbide
• Tungsten Carbide
• Comparison
• Choose the Right Material
• Conclusion

A mechanical seal works by maintaining a thin fluid film between two flat faces — one rotating, one stationary. These faces are under constant friction, pressure, and exposure to the process fluid. The wrong material choice can lead to:

• Excessive wear and heat generation
• Cracking due to thermal or mechanical shock
• Chemical attack and pitting
• Premature seal leakage and unplanned downtime

Choosing between Carbon, Silicon Carbide, and Tungsten Carbide isn’t just about hardness — it’s about matching material properties to your specific fluid chemistry, pressure-velocity (PV) conditions, and risk of dry-running.

Carbon-graphite is one of the oldest and most commonly used seal face materials, typically paired against a harder counter-face like silicon carbide, tungsten carbide, or ceramic.

Properties

• Soft and self-lubricating (Mohs hardness approximately 1–2)
• Excellent thermal shock resistance
• Low coefficient of friction
• Lightweight and easy to machine

Advantages

• Cost-effective compared to carbide options
• Performs well during brief dry-running or startup conditions
• Reduces wear on the harder mating face
• Good chemical compatibility with most neutral and mildly aggressive fluids

Limitations

• Poor resistance to abrasive particles in the fluid
• Can oxidize or “blister” at sustained high temperatures (typically above 200–250°C depending on grade and impregnation)
• Limited performance in strong oxidizing acids unless resin or metal-impregnated grades are used

Best Applications

• Water and wastewater pumps
• Light hydrocarbons and clean process fluids
• General-purpose industrial pumps with moderate pressure and temperature
• Applications where occasional dry-start protection is needed

Silicon Carbide is a high-performance ceramic material known for exceptional hardness and chemical resistance, making it a popular upgrade for demanding applications.

Properties

• Extremely hard (Mohs hardness approximately 9)
• High thermal conductivity, which helps dissipate frictional heat quickly
• Excellent resistance to most acids, alkalis, and solvents
• Brittle — low resistance to mechanical impact or thermal shock

Advantages

• Outstanding wear resistance, even in abrasive or solids-laden fluids
• Suitable for high-speed and high-pressure-velocity (PV) applications
• Long service life in chemically aggressive environments
• Available in reaction-bonded and sintered grades, allowing flexibility for different chemical exposures (sintered SiC generally offers better resistance to caustic and hydrofluoric acid environments since it contains no free silicon)

Limitations

• Brittle nature makes it prone to chipping or cracking under sudden thermal shock or mechanical impact
• Running SiC against SiC in dry-run conditions can cause rapid heat checking and face damage
• Higher initial cost compared to carbon

Best Applications

• Abrasive slurries and solids-bearing fluids
• Aggressive chemical processing applications
• High-speed pumps and compressors
• Applications requiring long mean-time-between-repairs (MTBR)

Tungsten Carbide combines extreme hardness with significantly better toughness than Silicon Carbide, making it a preferred choice where mechanical robustness is critical.

Properties

• Very high hardness (close to SiC) but with greater fracture toughness
• High density and excellent thermal conductivity
• Typically bound with a cobalt (or nickel) binder, usually around 6%
• Better resistance to thermal cycling and mechanical shock than SiC

Advantages

• Superior resistance to abrasive wear combined with impact resistance
• Performs reliably under high-pressure and high-load conditions
• Less prone to chipping during startup/shutdown cycles compared to SiC
• Excellent choice for boiler feedwater, high-pressure pumps, and oil & gas applications

Limitations

• The cobalt binder can be chemically attacked in highly acidic or corrosive media, leading to grain pull-out and accelerated wear over time
• Binderless or nickel-bound grades are available for corrosive services but at a higher cost
• Heavier and generally more expensive than carbon

Best Applications

• High-pressure boiler feed pumps
• Oil & gas processing equipment
• Abrasive applications where mechanical toughness is as important as hardness
• Heavy-duty industrial pumps with frequent start/stop cycles

When recommending a material combination, we typically evaluate four factors:

1. Fluid characteristics – Is the fluid abrasive, corrosive, or clean? Abrasive slurries point toward SiC or TC; clean fluids often work fine with a carbon vs SiC combination.
2. Operating temperature and pressure – High-pressure, high-PV applications generally demand SiC or TC over carbon.
3. Risk of dry-running – If dry-start is a concern, avoid SiC-vs-SiC combinations and consider carbon vs SiC or TC vs carbon.
4. Chemical compatibility of binders – For strongly acidic media, verify whether a binderless or nickel-bound TC grade is required instead of standard cobalt-bound TC.

There’s rarely a single “best” material — the right choice depends on matching these factors to your specific application. Combination pairings (such as Carbon vs Silicon Carbide, or Tungsten Carbide vs Tungsten Carbide) are often used precisely because they balance toughness, wear resistance, and dry-run tolerance.

Carbon offers cost-effective performance with excellent thermal shock resistance, Silicon Carbide delivers outstanding hardness and chemical resistance for demanding fluids, and Tungsten Carbide provides a robust balance of hardness and toughness for high-pressure, high-impact applications.

If you’re unsure which material combination is right for your pump or process equipment, Micro Seals’ engineering team can help you select and customize the ideal seal face pairing based on your specific operating conditions.
